Sys Framework |
Embedded Linux system
and ARM9 framework
(HI3518C) |
Embedded Linux system
and ARM9 framework
(HI3518C) |
Embedded Linux system
and ARM9 framework
(HI3516C) |
|
Sensor |
1/4" SOI CMOS Sensor |
1/3" Aptina CMOS Sensor |
1/2.9" SONY
CMOS Sensor |
|
Video Processing |
H.264 Video Code,Support dual-stream,
32k-8m adjustable,1-30/s frame rate adjustable |
|
Video Output |
Main stream:1280*720
Deputy stream:704*576 |
Main stream:1280*960
Deputy stream:704*576 |
Main stream:1920*1080
Deputy stream:704*576 |
|
Audio Port |
NO |
NO |
Support |
|
AudioProcessing |
NO |
NO |
G.711 coding Standard,
Support bothway Voice
intercom function,
support the
synchronization
of audio and video |
|
Network Port |
10M/100M self-adaption |
|
NetworkProtocol |
TCP/UDP/HTTP/MULTICAST/UPnP/NTP/RTSP/Onvif |
|
USB |
NO |
NO |
Support |
|
Auto Iris |
NO |
Support |
Support |
|
TF |
NO |
NO |
Support |
|
IR Led linkage |
1 photoconductive resistance interface, IR led board TTL
signal synchronization (alarm Sync:use for IR models, link
the IR led board through the sensor board l IR led board
synchronous interface level sync below 0.6V, module switch to
color mode; higher than 2.0V, less than 5V module switch to black
and white mode, IR led board synchronous signal high level requires
the driver 20K resistance strength) |
|
IR CUT |
Fixed pitch: 20mm; control pulse: 500ms, 5V |
|
Reset Port |
NO |
NO |
Support |
|
BNGVideo Output |
NO |
NO |
Support |
|
3G Wireless Transmission |
NO |
NO |
Support (optional) |
|
Wifi Transmisson |
NO |
NO |
Support (optional) |
|
Alarm Input |
NO |
NO |
Support |
|
Alarm Output |
NO |
NO |
Support |
|
Operation
Function |
Support Web setting,OSD,real-time video transmission,
support motive detection and IO alarm linkage for front end
shortage/Capture/playback/download,Support Central remind
and image linkage after motive detection and IO alarm linkage,
support MJPEG capture,Support unit clint-side romote
management software,Easy7 platform system apply |
|
Standard protocol |
Onvif 2.3 |
|
Mobile Phone Monitor |
Support Iphone,Windows Mobile,Android |
|
ProtectionRate |
ESD 1kv |
|
Power Supply
Temperature |
DC9V~12V,<3W
-35℃~65℃ |
|
Dimension |
38mm*38mm |
