Main Function |
TA1108FB |
|
Operating system |
Embedded Linux OS |
|
Video Compression Format |
Main Profile H.264 |
|
Video Input |
8 Channels BNC |
|
Video Output |
1 Channel BNC, 1 Channel VGA(1280*1024) |
|
Audio Input/Output |
8Channel RCA/1 Channel RCA |
|
Display Picture |
1/4/9CH |
|
Digital Zoom、PIP |
Supports |
|
Multiplex Operation |
Live\display\Playback\Recording\Backup\
Mobile phone Surveillance \Network simultaneously |
|
Display Resolution |
PAL:D1(704*576),NTSC:D1（704*480） |
|
Recording Mode |
Manual\Timer\Motion Detection\Alarm |
|
Recording Frame Rate |
PAL:D1@50fps,HD1@100fps,CIF@200fps
NTSC:D1@60fps,HD1@120fps,CIF@240fps |
|
Recording Resolution |
PAL:D1(704*576),HD1(704*288),CIF(352*288),
NTSC:D1(704*480),HD1(704*240),CIF(352*240) |
|
Recording Playback |
1/4/8channel playback simultaneously（Optional playback channel） |
|
Recording Backup |
USB、Moved Hard Disk、USB Writer、Network |
|
Network transmission |
8 Channels real-time Network transmission with QCIF resolution |
|
Recording Play |
Special player, Support AVI file format conversion |
|
JPEG capture function |
support,3M Pixels@10fps |
|
Alarm input/output |
8 channels input，1 channel output |
|
Action with Alarm |
Support |
|
Email Alarm |
Send pieces to the designated email |
|
SPOT Alarm pop-up |
Support |
|
Video Mask Alarm |
Support |
|
PTZ |
Supports PTZ preset ,Cruise Control and PC client port setup |
|
PTZ protocol |
PELCO-D,PELCO-P |
|
HDD |
Support 1 SATA HDD， capacity to 2T |
|
HDD Remain Time Hint |
Support |
|
Network and Protocol |
1 RJ-45 10/100M via Ethernet, Support TCP/IP、PPPOE、DHCP、DNS、DDNS、NTP、UPNP |
|
IE Browser |
Windows XP/Vista/Win 7/Mac OS,IE6.0-9.0/Firefox/Chrome/Opera/Apple Safari |
|
Client Software |
Support |
|
CMS |
Support(One software for at most 100 DVRs )，Free supply to use |
|
Dual Stream |
Support（Main and secondary interchange） |
|
Group play |
At least Support five users online access |
|
Privacy Mask |
Support |
|
S.E.Q |
Support single channel and grouping S.E.Q |
|
Watermark |
Support |
|
Multi-language |
Support |
|
Mobile Phone Surveillance |
Support Windows\ Symbian\ iPhone\Blackberry Operation System |
|
SDK Package |
Available |
|
Mouse Interface |
USB2.0 |
|
Backup interface |
USB2.0 |
|
Remote Controller |
Support（Supports controller ID matching） |
|
User Authority |
Support Multi-level user authority distribution |
|
Date and time Format |
adjustable |
|
DST |
Support |
|
Power |
DC12V/3A |
|
Working Temperature |
0℃-50℃ |
|
Working Humidity |
10%－90% |
|
Size |
354*230*45mm(L*D*H) |
