Description：
Features:
．Elegant ergonomic design
．Default verification mode is Fingerprint&Face, available to choose other 19 modes, such as RFID&Face, Face&PIN, Fingerprint only, RFID only.
．TCP/IP, RS232/485 communication and USB Host.
．3.0 inch TFT touch screen, T9 Input, 9 Digit User ID.
．2 user-defined function keys, the left one is for door belling, the right one is for shift of identification mode.
．Infra-red optical system enables user-identification in poorly lit environments.
．Wiegand input for working with wiegand reader, wiegand output for connecting to access control panel.
．Optional with ID card module or Mifare card module (available when using BioVX9.0 algorithm).
．Professional access control compatible with the 3rd party door sensor, alarm, exit button, wired bell and electric lock.
．50 time zones, 99 groups and 10 unlock combinations, anti-pass back and dismantle function.
Specifications:
|
CPU |
Multi-Bio CPU 630MHz |
|
Memory |
256M Flash, 64M SDRAM |
|
Hardware |
Platform: ZEM600 |
|
Fingerprint Sensor |
Optical Sensor |
|
Camera |
High Resolution Infrared Camera |
|
Display |
3 Inch Touch Screen |
|
Face Capacity |
400 (optional 3000) |
|
Fingerprint Capacity |
2000 (optional 5000) |
|
ID Card Capacity |
10,000(optional function) |
|
Logs Capacity |
10,000 |
|
Algorithm Version |
BioFace7.0(optional BioFace5.0) & BioVX10.0/BioVX9.0 |
|
2000mAh Backup Battery |
N/A |
|
Communication |
TCP/IP, RS232/485, USB Host |
|
Access Control Interfaces for |
3rd party electric lock, door sensor, alarm, wired bell and exit button |
|
Wiegand Signal |
Wiegand in and out |
|
Optional Functions |
ID Card, Mifare card. |
|
Power Supply |
12V/3A |
|
Verification Speed |
?2S |
|
Operating temperature |
0?-45? |
|
Operating Humidity |
20%-80% |
|
Dimensions |
275(L)*100(H)*195(W) mm |
|
Gross Weight |
0.87 kg | |
