Description：
Features:
Identification methods include Face,Fingerprint/RFID and/or Password
Elegant ergonomic design
4.3''TFT touch screen is user-friendly and very intuitive
6 user-defined function keys
Contact relays for door access control (wires to door strike or 3rd party panel)
Web server management software via IE browser.
Optional extendable scheduled-bell
Infra-red optical system enables user-identification in poorly lit environments
Optional built-in battery backup provides approx 4 hours continuous operation.
Optional built-in wireless Wi-Fi or GPRS for wireless communication.
Built-in contacts for 3rd party electric lock, door sensor, alarm, exit button, or bell.
Wiegand Output for connections to 3rd party access control panels.
Specifications:
|
CPU |
Multi-Bio CPU 630 MHz |
|
Memory |
256M Flash, 64M SDRAM |
|
Hardware Platform |
ZEM600 Multi-Medium Development Platform |
|
Fingerprint Sensor |
Optical Fingerprint Sensor without film |
|
Camera |
High Resolution Infrared Camera |
|
Display |
4.3’’ TFT touch screen |
|
Face capacity |
400 (1:N) |
|
Fingerprint capacity |
2000 |
|
ID Card capacity |
10,000 |
|
Logs capacity |
100,000 |
|
Algorithm Version |
Bio VX7.0 & Bio VX10.0 |
|
2000mAh backup battery |
Optional |
|
Communication |
TCP/IP,RS232/485 |
|
USB-HOST |
Two USB-Host |
|
Wireless Wi-Fi |
Optional |
|
Time attendance Standard functions |
ID Card(Optional), Automatic Status Switch, Self-Service Query, Work Code, T9 input, 9 digit user ID, DLST |
|
Access control interfaces for |
3rd party electric lock, door sensor, exit button |
|
Wiegand Signal |
Output |
|
Optional functions |
serial printer, Mifare card, Extendable Scheduled-bell, Short Massage, Web-server, GPRS |
|
Power supply |
12V3A |
|
Verification Speed |
≤2 sec |
|
Operating temp |
0℃- 45 ℃ |
|
Operating Humidity |
20%-80% |
|
Dimension |
193.6*165*111 mm (Length*Width*Thickness) |
|
Net Weight |
1.75 kg | |
